Generating Color Codes with Neural Networks

Introduction

In our digital world, colors are defined by codes. These color codes are essential for web design, digital art, and many other applications. But what if you could predict a color code based on a text description? This was the question I sought to answer with a recent machine learning project.

I developed a neural network that does just that – predict the RGB color code based on the color name. In this post, I will walk you through my approach.

Setting Up the Environment

First things first, I installed the necessary libraries in my environment:

!pip install numpy pandas keras tensorflow scikit-learn

I used Python for this project, and these libraries include tools for numerical operations, data handling, and machine learning.

Data Preprocessing

My dataset for this project was a CSV file with columns for color names and their corresponding RGB values. The RGB values were normalized to be between 0 and 1 for optimal neural network performance.

import pandas as pd
data = pd.read_csv('unique-v1.csv')
data[['r', 'g', 'b']] = data[['r', 'g', 'b']] / 255

Then, I used the Keras Tokenizer class to convert the color names into sequences of integers.

from keras.preprocessing.text import Tokenizer
tokenizer = Tokenizer()
tokenizer.fit_on_texts(data['color'])
sequences = tokenizer.texts_to_sequences(data['color'])

Loading Pre-trained Word Embeddings

To represent the words, I used pre-trained GloVe embeddings from Stanford. These embeddings transform the tokenized words into high-dimensional vectors that capture their semantic meanings.

!wget http://nlp.stanford.edu/data/glove.6B.zip
!unzip glove.6B.zip

The code for loading the embeddings is fairly straightforward. I ended up with an embedding matrix that I could use in my neural network.

Splitting the Data

To evaluate the performance of my model, I split the data into a training set and a validation set using a 80:20 ratio.

Model Training

The architecture of my model was relatively simple. I started with an embedding layer, followed by a global average pooling layer and a dense layer. The final layer was another dense layer with 3 units (for r, g, b) and a sigmoid activation function to ensure the output values were between 0 and 1.

from tensorflow.keras.layers import GlobalAveragePooling1D
model = Sequential([
    Embedding(input_dim=len(tokenizer.word_index) + 1, output_dim=embedding_dim, weights=[embedding_matrix], trainable=False),
    GlobalAveragePooling1D(),
    Dense(64, activation='relu'),
    Dense(3, activation='sigmoid')
])
model.compile(loss='mean_squared_error', optimizer='adam')
model.fit(x_train, y_train, validation_data=(x_val, y_val), epochs=500)

Color Prediction

Now for the fun part! With my trained model, I could take a color name and predict its RGB value. Here is how I did it for the color "yellow":

def get_rgb(color_text):
    # ... (omitted some code for brevity)
    predicted_color_rgb = model.predict(new_color_sequence)
    predicted_color_rgb = (predicted_color_rgb * 255).astype(int)
    img = Image.new('RGB', (300,300), color = tuple(predicted_color_rgb[0]))
    display(img)
get_rgb("yellow")

Voila! My neural network was able to generate the RGB value for "yellow" and create an image with the predicted color.

Lastly, I saved both the model and tokenizer for future use.

model.save('color_model.h5')
import pickle
with open('tokenizer.pickle', 'wb') as handle:
    pickle.dump(tokenizer, handle, protocol=pickle.HIGHEST_PROTOCOL)

I hope you found this exploration into the intersection of machine learning and color prediction intriguing. Let's keep pushing the boundaries of what we can achieve with these powerful tools!
